A75MH / A55MH
43
A75MH A55MH
Złącza
wbudowan
e
Złącze SATA3 x6 Złącze SATA2 x6
Złącze panela przedniego x1 Złącze panela przedniego x1
Przednie złącze audio x1 Przednie złącze audio x1
Złącze wyjścia S/PDIF x1 Złącze wyjścia S/PDIF x1
Złącze główkowe wentylatora procesora x1 Złącze główkowe wentylatora procesora x1
Złącze główkowe wentylatora systemowego x1 Złącze główkowe wentylatora systemowego x1
Złącze głó wkowe kasowania CMOS x1 Złącze główkowe kasowania CMOS x1
Złącze USB 2.0 x2 Złącze USB 2.0 x2
Złącze USB 3.0 x1 N/A
Złącze zasilania (24 pinowe) x1 Złącze zasilania (24 pinowe) x1
Złącze zas ilania (4 p ino we) x1 Złącze zas ilania (4 pino we) x1
Złącze Konsument IR x1 Złącze Konsument IR x1
Złącze Port drukarki x1 Złącze Port drukarki x1
Złącze Port szeregowy x1 Złącze Port szeregowy x1
Back Panel
I/O
Klawiatura / Mysz PS/2 x1
Port HDMI x1
Port VGA x1
Port DVI-D x1
Port LAN x1
Port USB 2.0 x2
Port USB 3.0 x2
Gniazdo audio x3
Klawiatura / Mysz PS/2 x1
Port HDMI x1
Port VGA x1
Port DVI-D x1
Port LAN x1
Port USB 2.0 x4
Gniazdo audio x3
Wymiary
płyty
200 mm (S) X 244 mm (W) 200 mm (S) X 244 mm (W)
Funkcje
specjalne
Obsługa RAID 0 / 1 / 10 Obsługa RAID 0 / 1 / 10
Obsluga
systemu
operacyjne
go
Windows XP / Vista / 7
Biostar zastrzega sobie prawo dodawania lub
odwoływania obsług i dowo lnego systemu
operacyjnego bez powiadomienia.
Windows XP / Vista / 7
Biostar zastrzega sobie prawo dodawania lub
odwoływania obsług i dowo lnego systemu
operacyjnego bez powiadomienia.
