Biostar A55MH Версия 6.x [40/51] Panish
![Biostar A55MH Версия 6.x [40/51] Panish](/views2/1711119/page40/bg28.png)
Motherboard Manual
38
SPANISH
A75MH A55MH
CPU
Conector FM1
Procesadores AMD A-Series / E2-Series
La arquitectura AMD 64 permite el procesado de
32 y 64 bits
Conector FM1
Procesadores AMD A-Series / E2-Series
La arquitectura AMD 64 permite el procesado de
32 y 64 bits
Conjunto
de chips
AMD A75 AMD A55
Súper E/S
ITE 8728
Le ofrece las funcionalidades heredadas de uso
más común Súper E/S.
Interfaz de cuenta Low Pin
In ic iat ivas de control d e entorno,
Monitor hardware
Función "Guardia inteligente" de ITE
ITE 8728
Le ofrece las funcionalidades heredadas de uso
más común Súper E/S.
Interfaz de cuenta Low Pin
In ic iat ivas de control d e entorno,
Monitor hardware
Función "Guardia inteligente" de ITE
Memoria
principal
Ranuras DIMM DDR3 x 2
Capacidad máxima de memoria de 16GB
Cada DIMM admite DDR de 512MB y
1GB/2GB/4GB/8GB
Módulo de memoria DDR3 de canal Doble
Admite DDR3 de 800/1066/1333/1600/1866
No admite DIMM registrados o DIMM
compatibles con ECC
Ranuras DIMM DDR3 x 2
Capacidad máxima de memoria de 16GB
Cada DIMM admite DDR de 512MB y
1GB/2GB/4GB/8GB
Módulo de memoria DDR3 de canal Doble
Admite DDR3 de 800/1066/1333/1600/1866
No admite DIMM registrados o DIMM
compatibles con ECC
SATA3/
SATA2
Controlador ATA Serie Integrado
Tasas de transferencia de hasta 6 Gb/s
Compat ib le con la versión SATA 3.0
Controlador ATA Serie Integrado
Tasas de transferencia de hasta 3 Gb/s
Compat ib le con la versión SATA 2.0
Red Local
Realtek RTL 8111E/8111F
Negociación de 10 / 100 / 1000 Mb/s
Funciones Half / Full dúplex
Realtek RTL 8111E/8111F
Negociación de 10 / 100 / 1000 Mb/s
Funciones Half / Full dúplex
Soporte de
sonido HD
VT1708B/ALC662
Salida de sonido de 5.1 canales
Soporte de sonido Alta Definición
VT1708B/ALC662
Salida de sonido de 5.1 canales
Soporte de sonido Alta Definición
USB3.0
A75 N/A
Ranuras
Ranura PCI Express Gen2 x16 X1 Ranura PCI Express Gen2 x16 X1
Ranura PCI Express Gen2 x1 X2 Ranura PCI Express Gen2 x1 X2
Ranura PCI X1 Ranura PCI X1
