Motherboard Manual
34
FRENCH
A75MH A55MH
UC
Socket FM1
Processeurs AMD A-Series / E2-Series
L'architecture AMD 64 permet le calcul 32 et 64
bits
Socket FM1
Processeurs AMD A-Series / E2-Series
L'architecture AMD 64 permet le calcul 32 et 64
bits
Chipset
AMD A75 AMD A55
Super E/S
ITE 8728
Fournit la fonctionnalité de Super E/S
patrimoniales la plus utilisée.
Interface à faib le co mpte de b roches
Initiatives de contrôle environnementales
Moniteur de mat ériel
Fonction "Gardien intelligent" de l'ITE
ITE 8728
Fournit la fonctionnalité de Super E/S
patrimoniales la plus utilisée.
Interface à faib le co mpte de b roches
Initiatives de contrôle environnementales
Moniteur de mat ériel
Fonction "Gardien intelligent" de l'ITE
Mémoire
principale
Fentes DDR3 DIMM x 2
Capacité mémo ire max imale de 16Go
Chaque DIMM prend en charge des DDR3 de
256 Mo/512 Mo et 1Go/2Go/4Go/8Go
Module de mémoire DDR3 à mode à double voie
Prend en charge la DDR3
800/1066/1333/1600/1866
Les DIMM à registres et DIMM avec code
correcteurs d'erreurs ne sont pas prises en
charge
Fentes DDR3 DIMM x 2
Capacité mémo ire max imale de 16Go
Chaque DIMM prend en charge des DDR3 de
256 Mo/512 Mo et 1Go/2Go/4Go/8Go
Module de mémoire DDR3 à mode à double voie
Prend en charge la DDR3
800/1066/1333/1600/1866
Les DIMM à registres et DIMM avec code
correcteurs d'erreurs ne sont pas prises en
charge
SATA3/
SATA2
Contrôleur Serial ATA
int égr é
Taux de transfert jusqu'à 6 Go/s
Conforme à la spéc if icat ion SATA Vers ion 3.0
Contrôleur Serial ATA
int égr é
Taux de transfert jusqu'à 3 Go/s
Conforme à la spéc if icat ion SATA Vers ion 2.0
LAN
Realtek RTL 8111E/8111F
10 / 100 / 1000 Mb/s négociation automatique
Half / Full duplex capability
Realtek RTL 8111E/8111F
10 / 100 / 1000 Mb/s négociation automatique
Half / Full duplex capability
Prise en
charge
audio HD
VT1708B/ALC662
Sortie audio à 5.1 vo ies
Prise en charge de l'audio haute définit ion
VT1708B/ALC662
Sortie audio à 5.1 vo ies
Prise en charge de l'audio haute définit ion
USB3.0 A75 N/A
Fentes
Fente PCI Express Gen2 x16 x1 Fente PCI Express Gen2 x16 x1
Fente PCI Express Gen2 x1 x2 Fente PCI Express Gen2 x1 x2
Fente PCI x1 Fente PCI x1
