A75MH / A55MH
45
A75MH A55MH
Встроенный
разъём
Разъём SATA3 x6 Разъём SATA2 x6
Разъём на лицевой панели x1 Разъём на лицевой панели x1
Входной звуковой разъём x1 Входной звуковой разъём x1
Разъём вывода для S/PDIF x1 Разъём вывода для S/PDIF x1
Контактирующее приспособление
вентил ятора центрального
процессора x1
Контактирующее приспособление
вентил ятора центрального
процессора x1
Контактирующее приспособление
вентил ятора системы x1
Контактирующее приспособление
вентил ятора системы x1
Открытое контактирующее
приспособление CMOS x1
Открытое контактирующее
приспособление CMOS x1
USB 2.0-разъём x2 USB 2.0-разъём x2
USB 3.0-разъём x1 N/A
Разъем питания (24 вывод) x1 Разъем питания (24 вывод) x1
Разъем питания (4 вывод) x1 Разъем питания (4 вывод) x1
Разъём едока ИКЫЙ x1 Разъём едока ИКЫЙ x1
Разъём Порт подключения
принтера x1
Разъём Порт подключения
принтера x1
Разъём Последовательный порт x1 Разъём Последовательный порт x1
Задняя
панель
средств
ввода-вывод
а
Клавиатура / Мышь PS/2 x1
Порт HDMI x1
Порт VGA x1
Порт DVI-D x1
Порт LAN x1
USB 2.0-порт x2
USB 3.0-порт x2
Гнездо для подключения
наушников x3
Клавиатура / Мышь PS/2 x1
Порт HDMI x1
Порт VGA x1
Порт DVI-D x1
Порт LAN x1
USB 2.0-порт x4
Гнездо для подключения
наушников x3
Размер
панели
200 мм (Ш) X 244 мм (В) 200 мм (Ш) X 244 мм (В)
Специальные
технические
характеристи
ки
Поддержка RAID 0 / 1 / 10 Поддержка RAID 0 / 1 / 10
Поддержка
OS
Windows XP / Vista / 7
Biostar сохраняет за собой право добавлять
или удалять средства обеспечения для OS с
или без предварительного уведомления.
Windows XP / Vista / 7
Biostar сохраняет за собой право добавлять
или удалять средства обеспечения для OS с
или без предварительного уведомления.
