A75MH / A55MH
49
A75MH A55MH
オンボード
コネクタ
SATA3コネクタ x6 SATA2コネクタ x6
フロントパネルコネクタ x1 フロントパネルコネクタ x1
フロントオーディオコネクタ x1 フロントオーディオコネクタ x1
S/PDIFアウトコネクタ x1 S/PDIFアウトコネクタ x1
CPUファンヘッダ x1 CPUファンヘッダ x1
システムファンヘッダ x1 システムファンヘッダ x1
CMOSクリアヘッダ x1 CMOSクリアヘッダ x1
USB 2.0コネクタ x2 USB 2.0コネクタ x2
USB 3.0コネクタ x1 N/A
電源コネクタ(24ピン) x1 電源コネクタ(24ピン) x1
電源コネクタ(4ピン) x1 電源コネクタ(4ピン) x1
消費者IR コネクタ x1 消費者IR コネクタ x1
プリンタポートコネクタ x1 プリンタポートコネクタ x1
シリアルポートコネクタ x1 シリアルポートコネクタ x1
背面パネル
I/O
PS/2キーボード / マウス x1
HDMIポート x1
VGAポート x1
DVI-Dポート x1
LANポート x1
USB 2.0ポート(で SB850) x2
USB 3.0ポート (で A75) x2
オーディオジャック x3
PS/2キーボード / マウス x1
HDMIポート x1
VGAポート x1
DVI-Dポート x1
LANポート x1
USB 2.0ポート x4
オーディオジャック x3
ボードサイ
ズ
200 mm (幅) X 244 mm (高さ) 200 mm (幅) X 244 mm (高さ)
特殊機能
RAID 0 / 1 / 10 のサポート RAID 0 / 1 / 10 のサポート
OSサポート
Windows XP / Vista / 7
Biostarは事前のサポートなしにOSサポートを追加ま
たは削除する権利を留保します。
Windows XP / Vista / 7
Biostarは事前のサポートなしにOSサポートを追加ま
たは削除する権利を留保します。
2012/06/11
