![Biostar A55MH Версия 6.x [46/51] Ussian](/views2/1711119/page46/bg2e.png)
Motherboard Manual
44
RUSSIAN
A75MH A55MH
CPU
(центральны
й процессор)
Гнездо FM1
Процессоры AMD A-Series / E2-Series
Архитектура AMD 64 разрешать обработка
данных на 32 и 64 бит
Гнездо FM1
Процессоры AMD A-Series / E2-Series
Архитектура AMD 64 разрешать обработка
данных на 32 и 64 бит
Набор
микросхем
AMD A75 AMD A55
Основная
память
Слоты DDR3 DIMM x 2
Максимальная ёмкость памяти 16ГБ
Каждый модуль DIMM поддерживает 512МБ
& 1ГБ/2ГБ/4ГБ/8ГБ DDR3
Модуль памяти с двухканальным режимом
DDR3
Поддержка DDR3
800/1066/1333/1600/1866
Не поддерживает зарегистрированные
модули DIMM and ECC DIMM
Слоты DDR3 DIMM x 2
Максимальная ёмкость памяти 16ГБ
Каждый модуль DIMM поддерживает 512МБ
& 1ГБ/2ГБ/4ГБ/8ГБ DDR3
Модуль памяти с двухканальным режимом
DDR3
Поддержка DDR3
800/1066/1333/1600/1866
Не поддерживает зарегистрированные
модули DIMM and ECC DIMM
Super I/O
ITE 8728
Обеспечивает наиболее используемые
действующие функциональные
возможности Super I/O.
Интерфейс с низким количеством выводов
Инициативы по охране окружающей среды,
Аппаратный монитор
Функция ITE "Smart Guard ian"
(Интеллектуальная защита)
ITE 8728
Обеспечивает наиболее используемые
действующие функциональные
возможности Super I/O.
Интерфейс с низким количеством выводов
Инициативы по охране окружающей среды,
Аппаратный монитор
Функция ITE "Smart Guard ian"
(Интеллектуальная защита)
SATA3/
SATA2
Встроенное последовательное устройство
управления ATA
скорость передачи данных до 6 гигабит/с.
Соответствие спецификации SATA версия
3.0
Встроенное последовательное устройство
управления ATA
скорость передачи данных до 3 гигабит/с.
Соответствие спецификации SATA версия
2.0
Локальная
сеть
Realtek RTL 8111E/8111F
Автоматическое согласование 10 / 100 /
1000 Мб/с
Частичная / полная дуплексная способность
Realtek RTL 8111E/8111F
Автоматическое согласование 10 / 100 /
1000 Мб/с
Частичная / полная дуплексная способность
Звуковая
поддержка
жесткого
диска
VT1708B/ALC662
Звуковая поддержка High-Defin ition
5.1канальный звуковой выход
VT1708B/ALC662
Звуковая поддержка High-Defin ition
5.1канальный звуковой выход
USB3.0
A75 N/A
Слоты
Слот PCI Express Gen2 x16 x1
Слот PCI Express Gen2 x16 x1
Слот PCI Express Gen2 x1 x2 Слот PCI Express Gen2 x1 x2
Слот PCI x1 Слот PCI x1
