Motherboard Manual
2
1.3 MOTHERBOARD FEATURES
SPEC
CPU
Socket AM2+
AMD Athlon 64 / Athlon 64 FX
/
Athlon 64
x2 / Sempron / Pheno m processors
AMD 64 Architecture enables 32 and 64 bit computing
Supports Hyper Transport 3.0 and Cool=n=Quiet
FSB
Support HyperTransport 3.0
Supports up to 5.2 GT/s Bandwidth
Chipset GeForce 8200
Super I/O
ITE 8718F
Provides the most commonly used legacy
Super I/O functionality.
Low Pin Count Interface
Env ironment Control in it iatives,
H/W Monitor
Fan Sp eed Contro ller
ITE's "Smart Guard ian" funct ion
Main
Memory
DIMM Slots x 4
Each DIMM supports 256MB/512MB/
1GB/2GB/4GB DDR2
Max Memory Capicity 16GB
Dual Channel Mode DDR2 memory module
Supports DDR2 533 / 667 / 800
Supports DDR2 1066 (by AM2+ CPU)
Registered DIMM and ECC DIMM is not supported
Graphics Integrated in GeForce 8200 Chipset
Max Shared V id eo Memory is 512 MB
DX10 / HDCP / PureV ideo support
IDE Integr ated IDE Contro ller
Ultra DMA 33 / 66 / 100 / 133 Bus Master Mode
supports PIO Mode 0~4
SATA II Integrated Serial ATA Controller
Data transfer rates up to 3 Gb/s.
SATA Version 2.0 specif ic at ion co mp liant.
LAN Realtek RTL 8111C
10 / 100 / 1000 Mb/s auto negotiation
Half / Full duplex capability
Sound
ALC888S /
Integrated in GeForce 8200 (for HDMI
Audio)
7.1 channels audio out (ALC888S)
2 channels audio out (for HDMI Audio)
Supports HD Audio
PCI slot x3 Supports PCI expansion cards
DVI-I Ad apter s lot x1 Supports specif ied DV I-I Ad apter
PCI Express Gen2 x16 slot x1 Supports PCI-E Gen2 x16 expansion cards
Slots
PCI Express x1 slot x2 Supports PCI-E x1 expansion cards
