TF8200 A2+
3
SPEC
Floppy connector x1 Each connector supports 2 Floppy drives
Printer Port connector x1 Each connector supports 1 Printer port
IDE Connector x1 Each connector supports 2 IDE device
SATA Connector x6 Each connector supports 1 SATA devices
Front Panel Connector x1 Supports front panel facilities
Front Audio Connector x1 Supports front panel audio function
CD-in Connector x1 Supports CD audio-in function
S/PDIF out connector x1 Supports digital audio out function
S/PDIF in connector x1 Supports digital audio-in function
CPU Fan header x1 CPU Fan power supply (with Smart Fan function)
System Fan header x2 System Fan Power supply
CMOS clear header x1 Restore CMOS data to factory default
USB connector x4 Each connector supports 2 front panel USB ports
Serial port Connector x1 Connects to RS-232 Port
Power Connector (24pin) x1 Connects to Power supply
On Board
Connector
Power Connector (8pin) x1 Connects to Power supply
Back Panel
I/O
PS/2 Keyboard x1
PS/2 Mouse x1
LAN port x1
USB Port x4
Audio Jack x6
DVI port x1
HDMI port x1
VGA port x1
Connects to PS/2 Keyboard
Connects to PS/2 Mouse
Connect to RJ-45 ethernet cable
Connect to USB devices
Provide Audio-In/Out and microphone connection
Connect to DVI-D monitor
Connect to HDTV
Connect to D-SUB monitor
Board Size 225 mm (W) x 305 mm (L)
Special
Features
RAID 0 / 1 / 5 / 0+1 support
Hybr id SL I support (by nVID IA driver)
OS Support
Windows XP / VISTA
Biostar Reserves the right to add or remove support for
any OS With or without notice.
