TF8200 A2+

1.5 MOTHERBOARD LAYOUT

JKBMS1

JAUDIO2

FDD1

BAT1

JCDIN1

Codec

JSPDIF_OUT1

JATXPWR1

JPRNT1

Super I/O

JUSB3

DIMMB2

JCMOS1

JPANEL1

IDE1

JATXPWR2

JCFAN1

JNFAN1

DIMMA2

DIMMA1

DIMMB1

Socket AM2+

PCI3

PCI2

GeForce

8200

JAUDIOF1

PWRSW1

RSTSW1

JUSBLAN1

JSFAN1

PEX16_1

JUSB5

JUSB4

BIOS

LAN

PCI1

SATA6

SATA5

SATA4

SATA3

SATA2

SATA1

JSPDIF_IN1

JCOM1

LED_D2

LED_D3

JHDMI1

VGA

DV I

PEX1_2

PEX1_1

DVI-I

JUSB1 JUSB2

J USB V2

JKBV1

JUSB V1

Note: represents the 1■

pin.
