TF8200 A2+
49
SPEC
Connecteur SATA x6
Chaque connecteur prend en charg e 1 périphérique
SATA
Connecteur du panneau avant x1 Prend en charge les équipements du panneau avant
Connecteur Audio du panneau avant x1 Prend en charge la fonction audio du panneau avant
Connecteur d'entrée CD x1 Prend en charge la fonction d'entrée audio de CD
Connecteur de sortie S/PDIF x1 Prend en charge la fonction de sortie audio numérique
Connecteur d'entrée S/PDIF x1 Prend en charge la fonction d'entrée audio numérique
Embase de ventilateur UC x1
Alimentation électrique du ventilateur UC (avec
fonction de ventilateur intelligent)
Embase de ventilateur système x2 Alimentation électrique du ventilateur système
Embase d'effacement CMOS x1
Connecteur USB x4
Chaque connecteur prend en charge 2 ports USB de
panneau avant
Connecteur de Port série x1
Connecteur d'alimentation x1
(24 broches)
Connecteur d'alimentation x1
(8 broches)
E/S du
panneau
arrière
Clavier PS/2 x1
Souris PS/2 x1
Port LAN x1
Port USB x4
Fiche audio x6
Port DVI x1
Port HD MI x1
Port VGA x1
Dimensions
de la carte
225 mm (l) X 305 mm (H)
Fonctionnali
tés
spéciales
Prise en charge RAID 0 / 1 / 5 / 0+1
Pr ise en ch arg e Hybr id SL I (by nV IDIA
driver)
Support SE Windows XP / VISTA
Biostar se réserve le droit d'ajouter ou de supprimer le
support de SE avec ou sans préavis.
