TF8200 A2+
59
СПЕЦ
Разъ ём SATA x6 Каждый разъём поддерживает 1 устройство SATA
Разъ ём на лицевой панели x1 Поддержка устройств на лицевой панели
Входной звуковой разъём x1
Поддержка звуко вых функций на лицевой
панели
Разъ ём ввода для CD x1 Поддержка функции ввода для CD
Разъ ём вывода для S/PDIF x1 Поддержка вывода цифровой звуковой функц ии
Разъ ём ввода для S/PDIF x1 Поддержка ввода цифровой звуковой функции
Контактирующее приспособление
вентилятора центрального процессора x1
Источник питания для вентилятор а центрального
процессора (с функц ией интеллектуального
вентилятора)
Контактирующее приспособление
вентилятора системы x2
Источник питания для вентилятор а системы
Открытое контактирующее
приспособление CMOS x1
USB-разъём x4
Каждый разъём поддерживает 2 USB-порта на
лицевой панели
Разъ ём Последовательный порт x1
Разъ ем питания (24 вывод) x1
Разъ ем питания (8 вывод) x1
Задняя
панель
средств
ввода-выв
ода
Клавиатура PS/2 x1
Мышь PS/2 x1
Порт LAN x1
USB-порт x4
Гнездо для подключения
наушников x6
Порт DVI x1
Порт HDMI x1
Порт VGA x1
Размер
панели
225 мм (Ш) X 305 мм (В)
Специальн
ые
технически
е
характерис
тики
Поддержка RAID 0 / 1 / 5 / 0+1
Поддержка Hyb r id SL I (by nV ID IA dr iver)
Поддержка
OS
Windows XP / VISTA
Biostar сохраняет за собой право добавлять или
удалять средства обеспечения для OS с или без
предварительного уведомления.
