Chapter 1 Motherboard Description

1-12

1.4 RAM Module Installation

1.4.1 DIMM

DRAM Access Time: 2.5V Unbuffered/ Registered DDR SDRAM PC1600/

PC2100 Type required.

DRAM Type : 64MB/ 128MB/ 256MB/ 512MB/ 1GB DIMM Module (184 pin)

Total Memory Size

Devices used on

DIMM

DIMM 1

(2 Rows)

x64

DIMM 2

(2 Rows)

x64

DIMM 3

(2 Rows)

x64

DIMM 4

(2 Rows)

x64

64M (4Mx4x4banks) 256 M 256 M 256 M 256 M

64M (2Mx8x4banks) 128 M 128 M 128 M 128 M

64M (1Mx16x4banks) 64 M 64 M 64 M 64 M

128M (8Mx4x4banks 512 M 512 M 512 M 512 M

128M (4Mx8x4banks) 256 M 256 M 256 M 256 M

128M (2Mx16x4banks) 128 M 128 M 128 M 128 M

256M (16Mx4x4banks) 1 G 1 G 1 G 1 G

256M (8Mx8x4banks) 512 M 512 M 512 M 512 M

256M (4Mx16x4banks) 256 M 256 M 256 M 256 M

512M (16Mx8x4banks) 1 G 1 G 1 G 1 G

512M (8Mx16x4banks) 512 M 512 M 512 M 512 M

* This M7VIB motherboard does not support with parity DIMM.

*T he list s hown ab ove fo r DRAM configuratio n is only for reference.
