Biostar M7VIB [21/73] Connectors headers jumpers

Chapter 1 Motherboard Description

1-16

1.6 Connectors, Headers & Jumpers

The connectors, headers and jumpers introduced below provide you lots of

capabilities such as power supply, front panel signal revelation, IDE hard disk

connection, floppy disk connection, Wake On LAN function and USB connection.

Noticeably, a jumper has two or more pins that can be covered by a plastic jumper

cap, allowing you to select a different system options.

CPU

FDD1

JPANEL1

JUSB2

JCMOS1

IDE1-2

JATXPWR1

JWOL1

DIMM1

DIMM2

DIMM3

DIMM4

Socket A

VT8366/A

Winbond

W83697

VT8233A

BIOS

JKBV1

JUSBV1
