Chapter 1 Motherboard Description

1-26

Connectivity

The serial ports can be used in many ways, and it may be necessary to become

familiar with the pinout diagram. The following chart gives you the function of

each pin on the 9-pin connector and some of the 25-pin connector. This information

can be used when configuring certain software programs to work with the serial

ports.

Signal Name DB9 PIN DB25 PIN

DCD Data Carrier Detect 1 8

RX Receive Data 2 3

TX Transmit Data 3 2

DTR Data Terminal Ready 4 20

GND Signal Ground 5 7

DSR Data Set Ready 6 6

RTS Request to Send 7 4

CTS Clear to Send 8 5

RI Ring Indicator 9 22
