ED34-645B Specifications
RXYQ-P 403
13
Notes:
★
1 Indoor temp. : 27°CDB, 19.5°CWB / outdoor temp. : 35°CDB / Equivalent piping length : 7.5m, level difference : 0m.
★
2 Indoor temp. : 27°CDB, 19.0°CWB / outdoor temp. : 35°CDB / Equivalent piping length : 7.5m, level difference : 0m.
★
3 Indoor temp. : 20°CDB / outdoor temp. : 7°CDB, 6°CWB / Equivalent piping length : 7.5m, level difference : 0m.
4 The power input (PI) (Comp. + Outdoor Fan Motor) : Refer to P.451~525.
5 The units with anti-corrosion treatment will be available as standard. Please specify the suffix “E” as RXYQ5PY1E.
Model Name (Combination Unit) RXYQ34PY1(E) RXYQ36PY1(E)
Model Name (Independent Unit) RXYQ16PY1(E)+RXYQ18PY1(E) RXYQ18PY1(E)+RXYQ18PY1(E)
★
1 Cooling Capacity (19.5°CWB)
kcal / h 81,400 85,100
Btu / h 323,000 338,000
kW 94.6 99.0
★2 Cooling Capacity (19.0°CWB)
kW
94.0 98.0
★3 Heating Capacity
kcal / h 92,000 97,200
Btu / h 365,000 386,000
kW 107 113
Casing Color Ivory White (5Y7.5/1) Ivory White (5Y7.5/1)
Dimensions: (H×W×D) mm (1680×1240×765)+(1680×1240×765) (1680×1240×765)+(1680×1240×765)
Heat Exchanger Cross Fin Coil Cross Fin Coil
Comp.
Type Hermetically Sealed Scroll Type Hermetically Sealed Scroll Type
Piston Displacement m³/h (13.72+10.53+10.53)+(13.72+10.53+10.53) (13.72+10.53+10.53)+(13.72+10.53+10.53)
Number of Revolutions r.p.m (6300, 2900, 2900)+(7980, 2900, 2900) (7980, 2900, 2900)+(7980, 2900, 2900)
Motor Output×Number
of Units
kW (1.4+4.5+4.5)×1+(3.0+4.5+4.5)×1 (3.0+4.5+4.5)×1+(3.0+4.5+4.5)×1
Starting Method Soft Start Soft Start
Fan
Type Propeller Fan Propeller Fan
Motor Output kW (0.35×2)+(0.75×2) (0.75×2)+(0.75×2)
Air Flow Rate m³/min 233+239 239+239
Drive Direct Drive Direct Drive
Connecting
Pipes
Liquid Pipe mm
φ
19.1 (Brazing Connection)
φ
19.1 (Brazing Connection)
Gas Pipe mm
φ
34.9 (Brazing Connection)
φ
41.3 (Brazing Connection)
Product Mass (Machine Weight) kg 329+341 341+341
Safety Devices
High Pressure Switch, Fan Driver Overload Protector, Over
Current Relay, Inverter Overload Protector
High Pressure Switch, Fan Driver Overload Protector, Over
Current Relay, Inverter Overload Protector
Defrost Method Deicer Deicer
Capacity Control % 5~100 4~100
Refrigerant
Refrigerant Name R-410A R-410A
Charge kg 12.5+12.7 12.7+12.7
Control Electronic Expansion Valve Electronic Expansion Valve
Refrigerator Oil Refer to the nameplate of compressor Refer to the nameplate of compressor
Standard Accessories Installation Manual, Operation Manual, Connection Pipes,
Clamps
Installation Manual, Operation Manual, Connection Pipes,
Clamps
Drawing No.
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3412
cfm=m³/min×35.3
