ED34-645B Accessories
RXYQ-P 537
13
11.Accessories
11.1 Standard Accessories
Q5~Q18 type
Name
Clamp (1) Clamp (2) Clamp (3) Gas side accessory pipe (1)
Quantity
9 pcs. 2 pcs. 1 pc. 1 pc.
Shape
Q5~Q18 type
Name
Gas side accessory
pipe (2)
Liquid side accessory
pipe (1)
Liquid side accessory
pipe (2)
Others
Quantity
1 pc. 1 pc. 1 pc.
• Operation
manual
• Installation
manual
• Declaration of conformity
(PED)
(8-18HP)
• “Request for the
Indication” label (Installation
Records)
Shape
Small
Large
5-10
HP type
12-18
HP type
5-10,
14,16
HP type
12,18
HP type
Operation manual
Installation manual
Clamps
Operation manual
Installation manual
Clamps
Accessory pipes
Accessory pipes
[ RXYQ5
.
8
.
10 type ] [ RXYQ12
.
14
.
16
.
18 type ]
