Specifications ED34-645B
396 RXYQ-P
1. Specifications
1.1 Heat Pump 50Hz-Normal Series (Space Saving Series) <RXYQ-P>
Notes:
★
1 Indoor temp. : 27°CDB, 19.5°CWB / outdoor temp. : 35°CDB / Equivalent piping length : 7.5m, level difference : 0m.
★
2 Indoor temp. : 27°CDB, 19.0°CWB / outdoor temp. : 35°CDB / Equivalent piping length : 7.5m, level difference : 0m.
★
3 Indoor temp. : 20°CDB / outdoor temp. : 7°CDB, 6°CWB / Equivalent piping length : 7.5m, level difference : 0m.
4 The power input (PI) (Comp. + Outdoor Fan Motor) : Refer to P.451~525.
5 The units with anti-corrosion treatment will be available as standard. Please specify the suffix “E” as RXYQ5PY1E.
Model Name RXYQ5PY1(E) RXYQ8PY1(E)
★
1 Cooling Capacity (19.5°CWB)
kcal / h 12,100 19,400
Btu / h 48,100 76,800
kW 14.1 22.5
★2 Cooling Capacity (19.0°CWB)
kW
14.0 22.4
★3 Heating Capacity
kcal / h 13,800 21,500
Btu / h 54,600 85,300
kW 16.0 25.0
Casing Color Ivory White (5Y7.5/1) Ivory White (5Y7.5/1)
Dimensions: (H×W×D) mm 1680×635×765 1680×930×765
Heat Exchanger Cross Fin Coil Cross Fin Coil
Comp.
Type Hermetically Sealed Scroll Type Hermetically Sealed Scroll Type
Piston Displacement m³/h 13.72 13.72
Number of Revolutions r.p.m 6300 7980
Motor Output×Number
of Units
kW 2.8×1 3.8×1
Starting Method Soft Start Soft Start
Fan
Type Propeller Fan Propeller Fan
Motor Output kW 0.35×1 0.75×1
Air Flow Rate m³/min 95 180
Drive Direct Drive Direct Drive
Connecting
Pipes
Liquid Pipe mm
φ
9.5 (Brazing Connection)
φ
9.5 (Brazing Connection)
Gas Pipe mm
φ
15.9 (Brazing Connection)
φ
19.1 (Brazing Connection)
Product Mass (Machine weight) kg 160 205
Safety Devices
High Pressure Switch, Fan Driver Overload Protector, Over
Current Relay, Inverter Overload Protector
High Pressure Switch, Fan Driver Overload Protector, Over
Current Relay, Inverter Overload Protector
Defrost Method Deicer Deicer
Capacity Control % 28~100 20~100
Refrigerant
Refrigerant Name R-410A R-410A
Charge kg 6.2 7.7
Control Electronic Expansion Valve Electronic Expansion Valve
Refrigerator Oil Refer to the nameplate of compressor Refer to the nameplate of compressor
Standard Accessories Installation Manual, Operation Manual, Clamps
Installation Manual, Operation Manual, Connection Pipes,
Clamps
Drawing No. C: 4D051441B C: 4D051442B
The Reference Number
C~: Partly corrected drawings.
J~: Original drawing is Japanese
V~: Printing Convenience
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3412
cfm=m³/min×35.3
