ED34-645B Control Devices
Control 737
16
Batch deletion of zone registration
1. Pressing the "ALL " for at least four seconds while pressing the "FILTER SIGN RESET"
button when "ZONE SET" is displayed will delete all zone registrations.
The zone registrations for all units will be lost.
3P124623-3A
Zone setting
Set the screen of [Zone 0] on the display, and if you set the following mode, you can set to the all zone registered on
the central remote controller by one operation.
Operation mode
Control mode
Room temperature setting
Time NO.
Display of "NOT AVAILABLE"
If indoor units are not available for functions subject to control even when attempting to operate these functions from
DCS302C(A)61, the system will display this "NOT AVAILABLE" message.
This message is displayed for a period of approximately two seconds. However, if any button corresponding to
functions not available while the "NOT AVAILABLE" is displayed, it will be displayed for a period of another
approximately two seconds.
The following section shows the conditions for this display.
On the Individual screen,
When the indoor unit is chosen, "NOT AVAILABLE" will be displayed if the "VENTILATION MODE ", "VENTILATION
STRENGTH" button is pushed.
When the HRV unit is chosen, "NOT AVAILABLE" will be displayed if the "OPERATION MODE SELECTOR", "FAN
DIRECTIOIN ADJUSTMENT" "FAN STRENGTH ADJUSTMENT" "TEMPERATURE ADJUSTMENT (ZONE
NUMBER)" button is pushed.
When an indoor without FAN DIRECTION, FAN STRENGTH is chosen, "NOT AVAILABLE" will be displayed if "FAN
DIRECTION", "FAN STRENGTH" button is pushed.
When a HRV without VENTILATION MODE, VENTILATION STRENGTH is chosen, "NOT AVAILABLE" will be
displayed if "VENTILATION MODE ", "VENTILATION STRENGTH" button is pushed.
On the Zone screen and All screen, the FAN DIRECTION ADJUSTMENT, FAN STRENGTH ADJUSTMENT,
VENTILATION MODE, and VENTILATION STRENGTH buttons are disabled.
Pressing any of these buttons will display the "NOT AVAILABLE" message on the screen.
With the Schedule Timer not connected, even if the "Timer No." button is pressed, the "NOT AVAILABLE" message
will not be displayed.
While in double central control function, even if the OPERATION CODE button is pressed, the "NOT AVAILABLE"
message will not be displayed.
9 8
