4 POWER INFORMATION

The power jack of VF-102-T / VF-102-R is with 2.5mm in the

central post and required +5VDC power input. It will conform to

the bundled AC-DC adapter and Planet’s Media Chassis. Should

you have the issue to make the power connection, please

contact your local sales representative.

Please keep the AC-DC adapter as spare parts when your VF-

102 is installed to a Media Chassis.

2.5mm

DC Receptacle 2.5mm

+5V for each slot

DC receptacle is 2.5mm wide that conforms to and matches

the Video over Fiber Converter 2.5mm DC jack’s central

post. Do not install any improper unit, model of the Video

over Fiber Converter.
