Planet VF-102-KIT [8/16] Product specification

1.4 PRODUCT SPECIFICATION

Model VF-102-T VF-102-R

Video Characteristic

Video Channel 1 channel Bi-direction

Signal Mode NTSC / PAL

Video Connector BNC

Video Input/Output

Impedance

75ohm / unbalanced interface

Video Input/Output

Voltage

1.0 Vpp / Typical peak-peak value

Video Bandwidth 6.5MHz

Video Digital Bit Width 8/10 bit

Differential Gain (DG) <1.3% (Typical Value)

Differential Phase (DP) <1.3° (Typical Value)

SNR Weighted 63dB (Typical Value)

Data Interface

Data Channel 1 channel

Physical Protocol RS-422 / RS-485

Operation Mode Simplex

Data Connector

3 Pin terminal block with screw

clamps

Data Rate DC-115.2Kbps

Data Distance RS-485: 0-1200m

Bit Error Rate (BER) < 10

-9

Optical Interface

Optical Connector FC

Fiber Type Single-mode, single ber

Distance (Max.) 20km for single mode
