22
Spanning (JBOD):
JBOD stands for “Just a Bunch of Disks”. Each drive is accessed as if it
were on a standard SCSI host bus adapter. This is useful when a single
drive configuration is needed, but it offers no speed improvement or
fault tolerance.
Features and Benefits
¾ Uses: JBOD works best if you have odd sized drives and you
want to combine them to make one big drive.
¾ Benefits: JBOD provides the ability to combine odd size drives
using all of the capacity of the drives.
¾ Drawbacks: Decreases performance because of the difficulty
in using drives concurrently.
¾ Fault Tolerance: Yes.
※ For more detailed setup information, please refer to the Driver CD, or
go to
http://www.nvidia.com/page/pg_20011106217193.html to download
NVIDIA nForce Tutorial Flash.
