2
Super I/O
Chip: ITE IT8712F.
Low Pin Count Interface.
Provides the most commonly used legacy Super I/O
functionality.
Environment Control initiatives,
- H/W Monitor
- Fan Speed Controller
- ITE's "Smart Guardian" function
On Board IDE
Supports 4 IDE disk drives.
Supports PIO mode 4, Block Mode and Ultra DMA
33/66/100/133 bus master mode.
10/100 LAN (optional)
PHY: RTL8201BLC
Supports 10 Mb/s and 100 Mb/s auto-negotiation.
Half/Full duplex capability.
Gigabit LAN
NVIDIA Gigabit MAC + VITESSE Gigabit PHY VSC8201
(CIS8201).
Supports 10 Mb/s, 100 Mb/s and 1Gb/s auto-negotiation.
Half/Full duplex capability.
Supports personal Firewall setup.
Supports ACPI power management.
Supports NVIDIA StreamThru technology
- Isochronous controller paired with Hyper Transport results
in fastest networking performance
Securi ty
NVIDIA Firewall technology
- Native firewall solution
Advanced features
- Remote access, configuration, monitoring
- Command line interface (CLI)
- WM I scri pts.
Serial ATA
Supports 2 serial ATA (SATA) ports.
Compliant with SATA 1.0 specification.
Data transfer rates up to 150 MB/s
