Biostar K8NHA Grand [51/63] Onboard device
![Biostar K8NHA Grand [51/63] Onboard device](/views2/1712331/page51/bg33.png)
17
drive and your system software both support Ultra DMA/100, select Auto to
enable BIOS support.
The Choices: Auto (default), Disabled.
IDE Prefetch Mode
The “onboard” IDE drive interfaces supports IDE prefetching for faster drive
access. If the interface does not support prefetching. If you install a primary
and/or secondary add-in IDE interface, set this option to “Disabled”.
The Ch o ices: En a b le d (default), Disabled.
IDE DMA Transfer Access
The Ch o ices: En a b le d (default), Disabled.
IDE HDD Block Mode
Block mode is also called block transfer, multip le commands, or multip le sector
read / write. If your IDE hard drive supports block mode (most new drives do),
select Enabled for automatic detection of the optimal number of block mode
(most new drives do), select Enabled for automatic detection of the optimal
number of block read / write per sector where the drive can support.
The Choices: Enabled (default), Disabled.
Onboard Device
If you highlight the literal “Press Enter” next to the “Onboard Device” label and then press the
enter key, it will take you a submenu with the following options:
OnChip USB
This option should be enab led if your system has a USB insta lled on the system
board. You will need to disable this feature if you add a higher performance
controller.
The Choices: V1. 1+V2. 0 (default), Disabled, V1.1
USB Legacy Support
This item allows you to support the USB legacy.
The Choices: Enabled (Default), Disabled.
USB Mouse Support
Enables support for USB attached mouse.
The Choices: Disabled (default), Enabled.
Serial-ATA
Enables support for Serial-ATA.
The Choices: Enabled (default), Disabled.
AC97 Audio
This option allows you to control the onboard AC97 audio.
The Choices: Auto (default), Disabled.
