18
MC97 Modem
This option allows you to control the onboard MC97 modem.
The Cho ices: Auto (default), Disabled.
MAC LAN (nVIDIA)
This option allows you to change the state of the onboard MAC LAN.
The Choices: Auto (Default), Disabled.
Onboard LAN Boot ROM
This item allows you to enable or disable Onboard LAN Boot ROM.
The Cho ices: Disabled (default), Enabled.
Onboard RAID ROM
This item allows you to enable or disable Onboard RAID ROM.
The Cho ices: Disabled (default), Enabled.
Onboard SATA ROM
This item allows you to enable or disable Onboard SATA ROM.
The Cho ices: Disabled (default), Enabled.
Reltek Giga LAN Boot ROM
This item allows you to enable or disable Reltek Giga LAN Boot ROM.
The Cho ices: Disabled (default), Enabled.
Reltek Mega LAN Boo t ROM
This item allows you to enable or disable Reltek Mega LAN Boot ROM.
The Cho ices: Disabled (default), Enabled.
Wi reless LAN Boot ROM
This item allows you to enable or disable Wireless LAN Boot ROM.
The Cho ices: Disabled (default), Enabled.
Super IO Device
Press Enter to configure the Super I/O Device.
O n boa rd FDC Co nt ro lle r
Select Enabled if your system has a floppy disk controller (FDC) installed on the
system board and you wish to use it. If install and FDC or the system has no
floppy drive, select Disabled in this field.
The Choices: Enabled (default), Disabled.
Onboard Serial Port 1
Select an address and corresponding interrupt for the first and second serial ports.
The Choices: 3F8/IRQ4 (default), Disabled, Auto, 2F8/IRQ3,
3E8/IRQ4, 2E8/IRQ3.
Onboard Serial Port 2
