CHAPTER 1: INTRODUCTION
1.1 K8NHA GRAND FEATURES
A. Hardware
CPU
Supports Socket 754.
Supports the AMD Athlon 64 Socket 754 processor
Supports AMD Sempron Socket 754 processor
Chipset
NVIDIA NF3 250Gb.
- Hyper Transport link to the AMD Athlon 64 CPU.
- Supports AGP 3.0 8x interface.
- Supports system and power management.
- Supports 4 IDE disk drives, integrated RAID 0, RAID 1 and
RAID 0+1 functions.
- Supports PIO Mode 5, Bride Mode and Ultra DMA
33/66/100/133 Bus Master Mode.
- Supports USB 2.0, 8 ports.
- Complaints with PCI Version 2.3 specification.
- Complaints with AC’97 Version 2.3 specification.
- Fast ATA/133 IDE controllers.
Dimensions
ATX Form Factor: 21.5x29.3cm (W x L)
Main Memory
Supports up to 2 DDR devices.
Supports 200/266/333/400 MHz DDR devices.
Certified DDR400+ List
- Please check the website:
http://www.biostar.com.tw/products/mainboard/board.php3
?name=K8NHA%20Grand
Maximum memory size is 2GB.
DIMM Socket
Location
DDR Module
To t al Me mo r y
Size (MB)
DIMM1 128MB/256MB/512MB/1GB *1
DIMM2 128MB/256MB/512MB/1GB *1
Max is 2 GB.
Slots
5 x 32-bi t PCI bus m aste r sl ots.
1 x AGP 8x slot
