Planet CAM-BX42 [2/2] Auto iris function

Auto Iris function

When use the Auto Iris Lens, the control switch should be in position AI to disable AES function. Before plug the enclosed

miniature 4 pins to IRIS connector, please check the type of Auto Iris Lens, and also the compatibility on the polarities.

If the Auto Iris Lens is DC DRIVE, the control switch should be in position DC DRIVE. Adjust the LEVEL with the

VR to proper.

If the Auto Iris Lens is VIDEO DRIVE, the control switch should be in VIDEO DRIVE position.

When using the Manual Iris Lens the switch is depend on application environment. Set control switch to BLC to enable BLC

function.

DC” VIDEO

Pin1

Drive- Volt +

Pin2 Drive+ N.C

Pin3 Damp+ IRIS

Pin4 Damp- GND

 Specification

Image pick-up device SONY 1/3“ CCD Normal Resolution

Effective Picture Elements NTSC: 510*492, PAL: 500*582 (H*V)

Horizontal Resolution 420 TVL

Minimum Illumination 0.05 LUX @ F1.2

Auto Electronic Shutter

ON : NTSC:1/60s~1/100,000s, PAL:1/50s~1/110,000s

OFF :NTSC:1/60s, PAL:1/50s

Signal To Noise Ratio More than 50dB (AGC Off)

Auto Iris Control Video-Drive Lens & DC-Drive Lens both supported

Gamma Characteristic 0.45

Lens Mount C or CS mount adjustable

Gain Control Automatically

White Balance Automatically (2500K~9500K)

Back Light Compensation ON/OFF Switch-able

Synchronous System Negative sync. Internal

Video Output 1 Vp-p Composite Video / 75 Ohms. BNC connector.

Power Request

DC12V/ 400mA , 50/60 Hz

Power Consumption

3.5W

Operating Temp.

-10℃ to 50℃ (14℉ to 122℉)

Part no.:2011-L00110-002
