Package Contents

● 1xCAM-IR442V

● 1xQuickInstallationGuide

Outlook

Front panel

IR LED

SENSOR

LENS

Rear panel

1.You can use a athead screwdriver to loose the FOCUS and

ZOOM’soutsidecoverscrewsforopening.

2.After opening the cover screws, use a crosshead screwdriver

to adjust the focus and zoom by turning the screws inside

mainbody.

3.Pleaseremembertolockthe coverscrews backtightly;other-

wiseitwillbedamagedandaffectthewaterresistance.

Physical Installation

1.Makethecameraonthebracketstable.

2.Connectthe75ohmcoaxialcabletodevice’svideoinput.

3.Attachtheexternalpowersupply

Note

Before connect power adapter to camera, please

make sure the power output voltage is DC 12V

(max. ±10%). If you can not sure this part, we

will suggest to use a DC 12V Switching power

adapter.Itcanprovidestablypoweroutput.

4.Adjustthecamerapoisonandangleindifferentenvironment.

Overview

Sunshade

Power Input

Video Output

Connector Denition

Connector Description

PowerInput Connecttoa12VDC,1.0Apoweradapter.

VideoOutput BNCconnectorforanalogvideooutput.
