PLANET IPX-1800 user’s manual

3.12.1 Add SIP Trunk

• Click <Add new> button from the left panel.

• Enter settings shown in Table 4-6.

• Click Save button.

The newly added SIP trunk shall be displayed in Trunks panel on the left side.

3.12.2 Edit SIP Trunk

• Click the link of the SIP trunk to edit from the Trunks panel.

• Edit settings shown on the right side.

• Click Save button.

3.12.3 Delete SIP Trunk

• Click the link of the SIP trunk to delete from the Trunks panel.

• Click Delete button.

The deleted SIP trunk shall disappear from the Trunks panel.

Table 4-6 SIP Trunk Configuration Settings

Field Description

Trunk identifier A unique number consisting of digits only.

Usually give the phone number issued by the

ITSP for consistency.

Description Arbitrary description info.

Dynamic peer Check if the trunk is a passive trunk which

means the registration will be from a dynamic

remote peer. Typical application is to accept

registration from an IP PBX at a remote site

with dynamic IP address. Once the remote IP

PBX registers, calls from local to remote can

be made reversely over the trunk.

SIP proxy IP or FQDN

SIP proxy port

Specify IP address (or fully qualified domain

name) and UDP port of the remote SIP proxy,

which usually refer to the SIP server on the

ITSP side.

SIP registrar IP or FQDN

SIP registrar port

Specify IP address (or fully qualified domain

name) and UDP port of the remote SIP

registrar, which usually refer to the SIP server

on the ITSP side (same as proxy).

Registration required Check if registration to a registrar is required

to activate the trunk. This is true for a remote

IP PBX or an ITSP account, however, may be

not required in case of a SIP gateway.
