PLANET IPX-1800 user’s manual
1.3 Installation
1. AC Powe
r
2. FXO port 2~4
3. FXS por
t
(lifeline)
4. USB por
t
5. WAN 6. LAN
Installation descriptions of IPX-1803
1. AC Power 110/220 Volt, 60 Hz
2. FXO ports 2~4 Connected directly to the PSTN analog line/CO line.
3. FXS port Connected Telephone to PBX for voice communication
4. USB ports 1 external port with compliance to USB 1.1/2.0. Plug in a
USB hard drive for CDR/voicemail backup from the internal
storage.
5. WAN Connect to a broadband modem or a WAN router.
6. LAN Connect to a LAN switch.
