Appendix SiEN34-705
168 General Information
During operation
(V1093)
Inspection item
Inspection method
Standard (guideline) Measurement values
Decision
Outdoor unit 1
Main power supply voltage
Tester
Rated voltage ±10%
R-S V S-T V R-T V
Operation circuit voltage
Tester
Rated voltage ±10%
V
Fan rotation direction
Visual inspection Forward rotation G NG
Fan noise/vibration Listening
No noise or vibration
Fan operation current
Clamp meter
RED WHITE BLACK
A A A
Suction air temperature
Thermometer
Temperature differential
9~11deg. when cooling,
2~3.5deg. when heating
°C
Discharge air temperature
Thermometer °C
Compressor discharge pressure
Pressure gauge MPa
Compressor suction pressure
Pressure gauge MPa
Compressor operating current
Clamp meter
Phase differential
within 1A
INV U( )A, V( )A, W( )A
STD1 R( )A, S( )A, T( )A
STD2 R( )A, S( )A, T( )A
Compressor operating frequency
Clamp meter INV Hz
Suction pipe temperature
Thermometer 3~15°C INV °C STD1 °C STD2 °C
Discharge pipe temperature
Thermometer 85~105°C INV °C STD1 °C STD2 °C
Clank case heater Touch Warm INV G·NG STD1 G·NG STD2 G·NG
Outdoor unit 2
Main power supply voltage
Tester
Rated voltage ±10%
R-S V R-S V R-S V
Operation circuit voltage
Tester
Rated voltage ±10%
V
Fan rotation direction
Visual inspection Forward rotation G NG
Fan noise/vibration Listening
No noise or vibration
Fan operation current
Clamp meter
RED WHITE BLACK
A A A
Suction air temperature
Thermometer
Temperature differential
9~11deg. when cooling,
2~3.5deg. when heating
°C
Discharge air temperature
Thermometer °C
Compressor discharge pressure
Pressure gauge
MPa
Compressor suction pressure
Pressure gauge MPa
Compressor operating current
Clamp meter
Phase differential
within 1A
INV U( )A, V( )A, W( )A
STD1 R( )A, S( )A, T( )A
STD2 R( )A, S( )A, T( )A
Compressor operating frequency
Clamp meter INV Hz
Suction pipe temperature
Thermometer 3~15°C INV °C STD1 °C STD2 °C
Discharge pipe temperature
Thermometer 85~105°C INV °C STD1 °C STD2 °C
Clank case heater Touch Warm INV G·NG STD1 G·NG STD2 G·NG
Outdoor unit 3
Main power supply voltage
Tester
Rated voltage ±10%
R-S V
R-S V R-S V
Operation circuit voltage
Tester
Rated voltage ±10%
V
Fan rotation direction
Visual inspection Forward rotation G NG
Fan noise/vibration Listening
No noise or vibration
Fan operation current
Clamp meter
RED WHITE BLACK
A A A
Suction air temperature
Thermometer
Temperature differential
9~11deg. when cooling,
2~3.5deg. when heating
°C
Discharge air temperature
Thermometer °C
Compressor discharge pressure
Pressure gauge
MPa
Compressor suction pressure
Pressure gauge MPa
Compressor operating current
Clamp meter
Phase differential
within 1A
INV U( )A, V( )A, W( )A
STD1 R( )A, S( )A, T( )A
STD2 R( )A, S( )A, T( )A
Compressor operating frequency
Clamp meter INV Hz
Suction pipe temperature
Thermometer 3~15°C INV °C STD1 °C STD2 °C
Discharge pipe temperature
Thermometer 85~105°C INV °C STD1 °C STD2 °C
Clank case heater Touch Warm NV G·NG STD1 G·NG STD2 G·NG
