Cleaning the AIR Filter

For better condition of cool system, please remember to clean the Air Filter every

three months. This section provides the procedure for how to clean the Air Filter

Procedure:

Note

Before cleaning the Air Filter, please power-off the IDL-2402 first.

You must loosen the connection of the Air Filter Panel to the DSLAM

and pull out the Air Filter before cleaning the air filter.

Screw

Air Filter Panel

1 Put on the antistatic wrist strap and connect it to a grounding point.

2 Turn the screw on the Air Filter Panel counterclockwise until it loosens the

connection of the panel to the DSLAM. Remove the Air Filter Panel.

3 Pull the air lter out of the DSLAM.

4 Wash and clean the dust that on the Air Filter.

5 Slide the cleaned Air Filter into the Air Filter slot of the DSLAM.

6 Reinstall the Air Filter Panel.
