Package Contents
IDL-2402
IDL-2402 unit x 1
AC Power Cord x 1
CD (Containing User’s Manual, QIG) x 1
Quick Installation Guide x 1
2-Meter Telco-50 Cable x 2
Console Cable x 1
Rack-mounting x 2
Screw Package x 2
If any of above items are damaged or missing, please contact your dealer
immediately.
Note
Using a power supply with a different voltage rating will damage
and void the warranty for this product.
