8
Step 3: Front Panel Connection
Power
outlet
Internet
MDF
IDL-PAN-48 (option)
LINE
PHONE
ADSL2/2+ CPE
Exchange /
PABX
Workstation
192.168.1.10/24
Uplink
Console
Cable
Switch
Front panel connection of IDL-2402
UPLINK Port: Connect to Internet by RJ-45 cable.
Console Port: Connect to PC by RS-232 console cable in order to administer your
IP DSLAM through CLI.
Step 4: Hook power cord and apply the power.
