1.1 Feature
Internet Access Features
Shared Internet Access: All users on the LAN can access the Internet through the
VDSL Router using only a single external IP Address. The local (invalid) IP
Addresses are hidden from external sources. This process is called NAT (Network
Address Translation).
Built-in VDSL2 Modem: The VDSL Router provides VDSL2 modem, and supports
all common VDSL2 connections.
Multiple WAN Connection: On the Internet (WAN port) connection, the VDSL
Router supports Dynamic IP Address (IP Address is allocated on connection), Fixed
IP Address, PPPoE, PPTP and L2TP.
CO and CPE type Support: The VDSL Router provides the Peer-to-Peer
connection. Users can select the CO and CPE mode manually.
Bridge and Router Application: The VDSL Router supports two application
modes. Currently, it comes pre-configured with routing mode. Note that, routing mode
and bridging mode cannot be used simultaneously.
Advanced Internet Functions
Virtual Servers: This feature allows Internet users to access Internet servers on
your LAN. The required setup is quick and easy.
Firewall: Supports simple firewall with NAT technology.
Universal Plug and Play (UPnP): UPnP allows automatic discovery and
configuration of the Broadband Router. UPnP is supported by Windows ME, XP, or
later.
Selectable VDSL2 Profiles: The VDSL Router supports common VDSL2 profiles
(30a, 17a, 12a, 12b, 8a, 8b, 8c, 8d) for selectable. Users can choose different
VDSL2 profiles based on their requirements.
User Friendly Interface: The VDSL Router can be managed and controlled
through Web UI.
DMZ Support: The VDSL Router can translate public IP addresses to private IP
address to allow unrestricted 2-way communication with Servers or individual users
on the Internet. This provides the most flexibility to run programs, which could be
incompatible in NAT environment.
Bridge and Router Application: The VDSL Router supports two application
modes. Currently, it comes pre-configured with routing mode. Note that, routing
mode and bridging mode cannot be used simultaneously.
RIP1/2 Routing: It supports RIPv1/2 routing protocol for routing capability.
VPN Pass through Support: PCs with VPN (Virtual Private Networking) software
are transparently supported - no configuration is required.
7
