LAN Features
4-Port Switch: The VDSL Router incorporates a 4-port 10/100Base-TX switching
hub, making it easy to create or extend your LAN.
DHCP Server Support: Dynamic Host Configuration Protocol provides a dynamic
IP address to PCs and other devices upon request. The VDSL Router can act as a
DHCP Server for devices on your local LAN.
Wireless Features(VC-230N only)
Support IEEE 802.11b, g and 802.11n Wireless Stations: The 802.11n standard
provides for backward compatibility with the 802.11b and 802.11g standard, so
802.11b, 802.11g, and 802.11n Draft 2.0 can be used simultaneously. IEEE 802.11n
(Draft 2.0) wireless technology is capable of up to 300Mbps data rate.
Two External Antennas with MIMO Technology: The VC-230N provides farther
coverage, less dead spaces and higher throughput with 2T2R MIMO technology.
WPS Push Button Control: The VC-230N supports WPS (Wi-Fi Protected Setup)
to easily connect to wireless network without configuring the security.
WEP Support: WEP (Wired Equivalent Privacy) is included. Key sizes of 64 Bit
and 128 Bit are supported.
WPA-PSK Support: WPA-PSK_TKIP and WAP-PSK_AES encryption are
supported.
Wireless MAC Access Control: The Wireless Access Control feature can check
the MAC address (hardware address) of Wireless stations to ensure that only trusted
Wireless Stations can access your LAN.
1.2 Package Contents
VC-230 / VC-230N Unit x 1
Power Adapter x 1
Quick Installation Guide x 1
User’s Manual CD x 1
RJ-45 cable x 1
RJ-11cable x 1
Antenna x 2 (VC-230N)
8
