28
Chapter 7: Services Tab EdgeRouter
™
Lite User Guide
Ubiquiti Networks, Inc.
Chapter 7: Services Tab
The Services tab displays status information about DHCP
servers, DNS forwarding, and the PPPoE server. Any setting
marked with a blue asterisk * is required.
You have three sub-tabs:
DHCP Server Configure DHCP servers to implement
different subnets on the independent interfaces.
DNS Configure DNS forwarding so the EdgeRouter
receives all LAN DNS requests and forwards them to the
service provider’s DNS server.
PPPoE Server Configure the PPPoE server so a remote
PPPoE client can establish a tunnel to the EdgeRouter for
network access.
DHCP Server
A DHCP server assigns IP addresses to DHCP clients. You
can configure multiple DHCP servers to assign IP ranges in
different subnets on the different interfaces.
Add DHCP Server To create a new DHCP server, click Add
DHCP Server.
The Create DHCP Server screen appears.
Complete the following:
• DHCP Name Enter a name for this DHCP server.
• Subnet Enter the IP address and subnet mask using
slash notation:
<network_IP_address>/<subnet_mask_number>
(example: 192.0.2.0/24).
• Range Start Enter the starting IP address of the range.
• Range Stop Enter the last IP address of the range.
• Router Enter the default route of the DHCP clients. The
DHCP clients route all packets to this IP address, which is
the EdgeRouter’s own IP address in most cases.
• DNS 1 Enter the IP address of the primary DNS server.
Your ISP may provide this information, or you can use
Google’s DNS server at 8.8.8.8.
• DNS 2 Enter the IP address of the secondary DNS server.
• Enable Check the box to enable this DHCP server.
Click Save to apply your changes, or click Cancel.
