Ubiquiti TOUGHSwitch PoE [10/43] Connecting ethernet

Chapter 2: InstallationTOUGHSwitch

™

PoE User Guide

Ubiquiti Networks, Inc.

Connecting Power

1. Connect the power connector of the Power Adapter to

the Power port of the TOUGHSwitch.

2. Connect the Power Cord to the power port on the

Power Adapter. Connect the other end of the Power

Cord to a poweroutlet.

Connecting Ethernet

1. Connect an Ethernet cable from the Ethernet port

of your computer to the Management port of the

TOUGHSwitch.

2. Connect Ethernet cables from the Ethernet ports

of your devices to the numbered ports of the

TOUGHSwitch.

Note: PoE is disabled by default on all numbered

ports and is not available on the Management port.

To enable PoE on the appropriate ports, use the Ports

tab in the Configuration Interface (see “PoE” on

page 24).
