Chapter 6. Hardware locations
This section provides information about the locations of your computer hardware.
Note: The computer hardware might look slightly different from the illustrations.
Overview
Attention: Be careful not to block any air vents on the computer. Blocked air vents can cause overheating.
1
2
3 4 5
77
6
Figure 1. Front view
1 Air vents
2 Camera cover slider
3 Camera indicator 4 Camera (standard or Windows Hello compatible)
5 Microphone
6 Screen
7 Wireless antennas
© Copyright Lenovo 2019 17
