Lenovo IdeaCentre AIO340-22IWL (F0EB009TRK) [31/57] Audio jack
![Lenovo IdeaCentre A340-22IGM (F0EA000MRK) [31/57] Audio jack](/views2/1733825/page31/bg1f.png)
1 Camera connector 2 Mic Connector
3 USB 3.1 connector 4 Card reader
5 Audio jack
6 Speaker connector
7 Fan connector 8 Touch connector
9 USB 2.0 connectors
10 HDMI-out connector
11 RJ45 connector
12 DC IN connector
13 Power board connector
14 LVDS FFC connector
15 HDD FFC connector 16 ODD FFC connector
17 Converter connector
1 Camera connector 2 Mic Connector
3 USB 3.1 Gen 1 connector 4 Card reader
5 Audio jack
6 Speaker connector
7 Fan connector 8 Touch connector
9 USB 2.0 connectors
10 HDMI-out connector
11 RJ45 connector
12 DC IN connector
13 Power board connector
14 LVDS FFC connector
15 HDD FFC connector 16 ODD FFC connector
17 Converter connector
Figure 8. Parts on the system board (A340-22AST)
Chapter 6. Hardware locations 25
