Инструкция по эксплуатации Страница: 25

Lenovo IdeaCentre AIO340-22IWL (F0EB009TRK) [25/57] Combo audio jack

1 USB 3.1 connector

2 Memory card slot

3 Combo audio jack 4 Optical drive (for select models)

5 Power button (with indicator) 6 Speakers

Chapter 6. Hardware locations 19
