1 2 3 4 5

Figure 2. Rear view

1 Power connector 2 Ethernet connector

3 HDMI-out connector

4 USB 2.0 connectors

5 USB 3.1 connector

Figure 3. Left view and right view

18 ideacentre A340 Hardware Maintenance Manual
