■ Set mode item list
Guidance Item Page
Repeater tone frequency
p. 5353
TSQL frequency
p. 5353
DTCS code
p. 5353
DTCS polarity
p. 5353
Tuning step
p. 5454
Frequency offset
p. 5454
Reverse duplex function
p. 5454
Operating mode
p. 5454
Weather alert
p. 5454
Priority watch
p. 5555
Scan pause timer
p. 5555
Scan resume timer
p. 5555
Program skip function
p. 5555
Bank link
p. 5656
Programmed scan link
p. 5656
DTMF TX key
p. 5858
DTMF memory setting
p. 5858
MIC gain
p. 5858
VOX function
p. 5858
VOX gain
p. 5858
VOX delay
p. 5959
VOX time-out timer
p. 5959
■ Initial set mode item list
Guidance Item Page
Microphone simple mode
p. 5959
Auto power OFF
p. 5959
Display backlight
p. 6060
Beep output level
p. 6060
Auto repeater
p. 6060
Power save
p. 6161
Voltage indication
p. 6161
DTMF speed
p. 6161
LCD contrast
p. 6262
PTT lock
p. 6262
Busy lockout
p. 6262
Time-out timer
p. 6262
Squelch delay
p. 6262
Monitor key action
p. 6363
Dial speed acceleration
p. 6363
Memory name
p. 6363
Scan name
p. 6363
Display type
p. 6464
HS-95 selection
p. 6464
Auto low power
p. 6464
