Icom IC-T70A [85/96] Options
![Icom IC-T70A [85/96] Options](/views2/1074089/page85/bg55.png)
New2001
78
13
OPTIONS
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
• BP-263 battery case
Battery case for LR6 (AA) × 6 alkaline batteries.
• BP-264
ni-mh battery pack
7.2 V/1400 mAh (Typ.) Ni-MH battery pack. Battery life:
11.5 hrs. (approx.; VHF, FM, high power, Tx : Rx : Standby
= 5:5:90)
Same as supplied
one. (Not supplied with some version.)
• BP-265 li-ion battery pack
7.4 V/1900 mAh (Min.)/2000 mAh (Typ.) Lithium Ion battery
pack. Battery life: 16 hrs. (approx.; VHF, FM, high power, Tx
: Rx : Standby = 5:5:90)
• BC-123S
ac adapter
AC adapter for the desktop charger, BC-191 or BC-193.
• BC-147S
ac adapter
AC adapter for the desktop charger, BC-192.
• BC-167S
battery charger
For regular charging of the Ni-MH battery pack, BP-264.
Same as supplied one. (Not supplied with some version.)
• BC-191
desktop charger+BC-123S ac adapter
For rapid charging of the Ni-MH battery pack, BP-264. An
AC adapter may be supplied with the charger, depending
on the version.
Charging time: Approx. 2 hours for the BP-264.
• BC-193
desktop charger+BC-123S ac adapter
For rapid charging of the Li-Ion battery pack, BP-265. An
AC adapter may be supplied with the charger, depending
on the version.
Charging time: Approx. 2.5 hours for the BP-265.
BC-191/BC-193 common specifications
Power supply voltage 12 to 16 V DC or the specified
Icom AC adapter (BC-123S)
Charging temp. range +10°C to +40°C;
+50°F to +104°F
Dimensions
(projections not included)
87.5(W)×53.7(H)×72.8(D) mm;
3
7
⁄16(W)×2
1
⁄8(H)×2
7
⁄8(D) in
• BC-192
desktop charger+BC-147S ac adapter
For regular charging of the Ni-MH battery pack, BP-264. An
AC adapter may be supplied with the charger, depending
on the version.
Charging time: Approx. 16 hours for the BP-264.
BC-192 specifications
Power supply voltage* 12 to 16 V DC or the specified
Icom AC adapter (BC-147S)
Charging temp. range 0°C to +45°C;
32°F to +113°F
Dimensions
(projections not included)
87.5(W)×53.7(H)×72.8(D) mm;
3
7
⁄16(W)×2
1
⁄8(H)×2
7
⁄8(D) in
* Charging time differs depending on the input voltage.
12 V : Approx. 36 hours
13.8 V : Approx. 21 hours
16 V : Approx. 16 hours
