![Icom IC-M412 [19/68] N setting tag channels](/img/pdf.png)
Icom IC-M412 [19/68] N setting tag channels
![Icom IC-M412 [19/68] N setting tag channels](/views2/1074279/page19/bg13.png)
11
4
SCAN OPERATION
New2001
4
n Setting TAG channels
For more efficient scanning, you can add desired channels as
TAG channels, or remove unwanted channels as TAG channels.
Channels that are not tagged will be skipped during scan-
ning. TAG channels can be independently assigned to each
channel group (USA, INT, CAN).
q Push [U/I/C] (both [Y] and [Z]) to select a desired chan-
nel group.
w
Select a desired channel to be set as a TAG channel.
e Hold down [TAG](SCAN) for 1 second to set the channel
as a TAG channel.
•“ ” appears.
r To cancel the TAG channel setting, repeat step e.
•“ ” disappears.
4 Clearing (or setting) all tagged channels
While holding down [HI/LO] on the microphone, hold down
[TAG](SCAN) for 3 seconds (until a long beep changes to two
short beeps) to clear all TAG channels in the channel group.
•RepeataboveproceduretosetallTAGchannels.
n Starting a scan
First, set scan type (Priority or Normal scan) and the scan
resume timer in the Set mode. (p. 45)
q Push [U/I/C] (both [Y] and [Z]) to select a desired chan-
nel group.
w Set TAG channels as described at left.
e Make sure the squelch is closed to start a scan.
r Push [SCAN] to start Priority or Normal scan.
•“SCAN”blinksinthechannelcommentdisplayduringscanning.
(During Priority scan, “16” appears beside the blinking “SCAN”
indication.)
•Abeeptonesoundsand“16”blinksinthechannelcomment
display when a signal is received on Channel 16 during Priority
scan.
•Whenasignalisdetected,thescanpausesuntilthesignaldis-
appears or resumes after pausing 5 seconds, depending on the
Set mode setting. (Channel 16 is still monitored during Priority
scan.)
•Push[Y] or [Z] to check the scanning TAG channels, to change
the scanning direction or to manually resume the scan.
t To stop the scan, push [SCAN] again.
[Example]: Starting a Normal scan.
Push
Scan starts.
When a signal is
received.
BlinksBlinks
Appears
