D Dimensions
148 (5
13
⁄16)
139.5 (5
1
⁄2)78 (3
1
⁄16)
164 (6
15
⁄32)
28.3 (1
1
⁄8)14.2 (
9
⁄16)111.2 (4
3
⁄8)
60.6 (2
3
⁄8)
Unit: mm (inch)
