Electric Characteristics ED41-015B
38 FDBG-A Series
13.Electric Characteristics
13.1 Cooling Only
C : 3D024204
Unit Combination Power Supply Compressor OFM IFM
Indoor Outdoor Hz - Volts Voltage Range MCA TOCA MFA LRA RLA kW FLA kW FLA
FDBG25AVE R25JV1
50 - 220
50 - 230
50 - 240
Max.50Hz 264V
Min.50Hz 198V
9.05
(∗1)
17.5
(∗2)
6.7
15
19.0
20.0
21.0
3.46
3.64
3.82
0.025 0.27 0.045 0.5
FDBG35AVE R35JV1 13.9 — 15
26.0
27.0
28.0
4.90
5.45
5.99
0.025 0.27 0.045 0.5
FDBG50AVE R50GV1 13.6 — 20
42
44
46
9.0
9.1
9.1
0.045 0.3 0.045 0.5
FDBG60AVE
R60GV1
R60GV1K
14.5 — 25
55
58
60
11.9
12.0
12.1
0.053 0.6 0.060 0.7
FDBG71AVE R71FUV1 16.5 22.1 25 78 12.4 0.050 0.6 0.060 0.7
FDBG71AVE R71FUY1
50 - 380/220
50 - 400/230
50 - 415/240
Max.50Hz
456/264V
Min.50Hz
342/198V
6.2 8.1 15 35 4.2 0.050 0.6 0.060 0.7
