Power Supply and Nomenclature ED41-015B
4 FDBG-A Series
3. Power Supply and Nomenclature
3.1 Low Static Pressure Type
3.1.1 Power Supply
Note: Power Supply Intake : Outdoor Units.
3.1.2 Nomenclature
Indoor Unit
Outdoor Unit
Symbol Power Supply Indoor Unit Outdoor Unit
V1 1φ, 220~240V, 50Hz
FDBG25AVE R25JV1
FDBG35AVE R35JV1
FDBG50AVE R50GV1
FDBG60AVE R60GV1(K)
FDBG71AVE R71FUV1
Y1
3φ, 380~415V, 50Hz
(4 wires)
FDBG71AVE R71FUY1
Duct Connection Low Static Pressure Type
FDB : Cooling Only
DIT Products
Capacity Index
Indicates Major Design Category
Power Supply Symbol
VE : 1φ 200~240V/220V 50Hz/60Hz
VE35FDB A
(P0001-1)
G
Outdoor Unit
R : Cooling Only
Capacity Index
Indicates Major Design Category
Power Supply Symbol
V1
Y1
High Outdoor Temperature Application
V135R J K
: 1φ 220~240V 50Hz
: 3φ 380~415V 50Hz
(P1247-1)
