ED41-015B Specification
FDBG-A Series 5
4. Specification
4.1 50Hz
Note: 1. ∗1 The above data are based on the following conditions.
Capacities are net, including a deduction for cooling for indoor fan motor heat.
Model
Indoor Unit FDBG25AVE FDBG35AVE FDBG50AVE FDBG60AVE FDBG71AVE
Outdoor Unit
V1 R25JV1 R35JV1 R50GV1 R60GV1, R60GV1K R71FUV1
Y1 — — — — R71FUY1
∗1 Cooling Capacity (1)/(2)/(3)
kW 2.64 / 2.60 / – 3.54 / 3.50 / – 5.34 / 5.30 / 4.80 7.03 / 6.97 / 6.09 7.80 / 7.70 / 6.30
Btu/h 9,000 / 8,900 / – 12,100 / 11,900 / –
18,200 / 18,100 / 16,400 24,000 / 23,800 / 20,800 26,600 / 26,200 / 21,500
kcal/h 2,270 / 2,250 / – 3,040 / 3,010 / – 4,590 / 4,560 / 4,100 6,050 / 6,000 / 5,240 6,700 / 6,600 / 5,400
Indoor Unit FDBG25AVE FDBG35AVE FDBG50AVE FDBG60AVE FDBG71AVE
Dimensions H×W×D mm 260×900×580 260×900×580 260×900×580 260×1,300×580 260×1,300×580
Coil
Type Cross Fin Coil (Waffle Louver Fins and Hi-XA Tubes)
Row×Stages×Fin Pitch 2×10×1.75 2×10×1.75 3×10×1.75 3×10×1.75 3×10×1.75
Face Area m² 0.189 0.189 0.189 0.231 0.231
Fan
Model — — — — —
Type Sirocco Fan Sirocco Fan Sirocco Fan Sirocco Fan Sirocco Fan
Motor Output W 45 45 45 65 65
Air Flow Rate m³/min (H) 13 (L) 11 (H) 13 (L) 11 (H) 13 (L) 11 (H) 18 (L) 15 (H) 18 (L) 15
Weight kg 22 22 23 31 31
Piping Connections
Liquid mm φ 6.4 (Flare) φ 6.4 (Flare) φ 6.4 (Flare) φ 6.4 (Flare) φ 9.5 (Flare)
Gas mm φ 9.5 (Flare) φ 12.7 (Flare) φ 15.9 (Flare) φ 15.9 (Flare) φ 15.9 (Flare)
Drain in. 3 / 4 B 3 / 4 B 3 / 4 B 3 / 4 B 3 / 4 B
Remote Controller
Wired KRC47-1 KRC47-2 KRC47-1 KRC47-2 KRC47-1 KRC47-2 KRC47-1 KRC47-2 KRC47-1 KRC47-2
Wireless — — — — —
Outdoor Unit
V1 R25JV1 R35JV1 R50GV1 R60GV1, R60GV1K R71FUV1
Y1 — — — — R71FUY1
Color Ivory White Ivory White Ivory White Ivory White Ivory
Dimensions H×W×D mm 560×695×265 560×695×265 540×750×270 685×800×300 816×880×370
Coil
Type Cross Fin Coil
Row×Stages×Fin Pitch 1×24×1.6 2×22×2.0 2×22×2.0 2×28×2.0 2×36×2.0
Face Area m² 0.333 0.372 0.372 0.465 0.653
Comp.
Model
V1 RC30BV1R2T RC46AV1TRT RC70AV1TRT NH41VMDT H23A35QABKA
Y1 — — — — H23A35QDBEA
Type Hermetically Sealed Rotary Type
Hermetically Sealed
Type
Motor Output kW 0.7 1.1 1.7 2.2 2.2
Fan
Model PZ380 PZ380 PZ380 PZ430 P45J11SM
Type Propeller Propeller Propeller Propeller Propeller
Motor Output W 25 25 45 53 50
Air Flow Rate m³/min 28 / 30 26.5 / 28 27 40 46
Weight kg
V1 27 33 42 61 87
Y1 — — — — 84
Piping Connections
Liquid mm φ 6.4 (Flare) φ 6.4 (Flare) φ 6.4 (Flare) φ 6.4 (Flare) φ 9.5 (Flare)
Gas mm φ 9.5 (Flare) φ 12.7 (Flare) φ 15.9 (Flare) φ 15.9 (Flare) φ 15.9 (Flare)
Drain mm φ 18.0 (Hole) φ 18.0 (Hole) φ 18.0 (Hole) φ 18.0 (Hole) φ 26.0 (Hole)
Safety Devices
Thermal Protector for Compressor (50 model), Outdoor Fan Motor and Indoor Fan Motor.
Internal Protector of Compressor. Fuse.
Thermal Protector for
Outdoor Fan Motor
and Indoor Fan Motor.
Internal Pressure
Relief Valve
(Compressor).
Motor Protector
(Compressor).
Capacity Step % 100 – 0 100 – 0 100 – 0 100 – 0 100 – 0
Refrigerant Control Capillary Tube
Ref. Piping
Standard Length m 5 5 5 5 5
Max. Length m 25 25 30 30
50 (Equivalent Length
70m)
Max. Height Difference m 15 15 15 15 30
Refrigerant
Model R22 R22 R22 R22 R22
Charge kg
0.8
(Charged for 10m)
1.0
(Charged for 10m)
1.20
(Charged for 10m)
1.50
(Charged for 5m)
2.10
(Charged for 5m)
Ref. Oil
Model SUNISO 4GS – DI SUNISO 4GS – DI SUNISO 4GS – DI MS – 32 SUNISO 3GS
Charge L 0.40 0.50 0.85 1.20 1.48
Drawing No. — C : 4D024196 C : 4D024536
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
Cooling Piping Length Hz-Volts Standard
(1)
Indoor:
Outdoor:
27°C(81°F)DB, 19.5°C(67°F)WB
35°C(95°F)DB, 24°C(75°F)WB
5m (Horizontal) 50Hz-220V —
(2)
Indoor:
Outdoor:
27°C(81°F)DB, 19.0°C(66°F)WB
35°C(95°F)DB, 24°C(75°F)WB
5m (Horizontal) 50Hz-220V —
(3)
Indoor:
Outdoor:
29°C(84°F)DB, 19.0°C(66°F)WB
46°C(115°F)DB, 24°C(75°F)WB
7.5m (Horizontal)
50Hz-220V
(380V)
