SiBE05-312 Outdoor Unit
Removal Procedure 137
Insert the two claws of the
lower part and the one claw
of the upper back when
reassembling.
2. Disconnect harnesses.
1
Loosen the fixing screw
of the cable way board.
Service monitor PCB
Step
Procedure Points
(
R2701
)
Claw
(R2702)
Claws
S52
SW1
ABC
LEDA(Green)
SW4
(Initial setting: OFF)
LED A (Green)
ON
SW4
S102
S2
(R2704)
