SiBE05-312 Troubleshooting
Service Diagnosis 71
4. Troubleshooting
4.1 Error Codes and Description
★
: Displayed only when system-down occurs.
Code Indication Description
Reference
Page
System
00
Normal
—
U0★
Insufficient gas
97
U2
Low-voltage detection
99
U4
Signal transmission error (between indoor and outdoor units)
77
Indoor
Unit
A1
Indoor unit PCB abnormality
72
A5
Freeze-up protection control or high pressure control
73
A6
Fan motor or related abnormality
75
C4
Heat exchanger thermistor abnormality
76
C9
Room temperature thermistor abnormality
76
Outdoor
Unit
E5★
OL activation (compressor overload)
78
E6★
Compressor lock
79
E7
DC fan lock
80
E8
Input over current detection
81
EA
Four way valve abnormality
83
F3
Discharge pipe temperature control
85
F6
High pressure control in cooling
100
H6
Position sensor abnormality
86
H8
CT or related abnormality
87
H9
Outdoor air thermistor or related abnormality
89
J3
Discharge pipe thermistor or related abnormality
89
J6
Heat exchanger thermistor or related abnormality
89
L3
Electrical box temperature rise
91
L4
Radiation fin temperature rise
93
L5
Output over current detection
95
P4
Radiation fin thermistor or related abnormality
89
